Schneider DC 2pole SPD Surge Protection Device 40kA 1000V DC
Key Features:
-
Power On Time: 1–500 Sec Adjustable
-
Over Voltage: 230–300V
-
Recovery Voltage (Over Voltage): 220–295V
-
Recovery Time (Over Voltage): 1–500 Sec Adjustable
-
Power Off Delay Time: 0.1–30 Sec
-
Under Voltage: 140–210V
-
Recovery Voltage (Under Voltage): 145–215V
-
Recovery Time (Under Voltage): 1–500 Sec
-
Current Protection: 1–63 Amp Adjustable
-
Delivery Available All Over Pakistan
Description
Description:
- This is the 2pole DC direct current surge protection device used mostly in solar and dc installations.
- It allows the quick replacement of damaged cartridges easily.
- The short circuit breaking capacity and the total discharge current is 40kA.
- The In nominal discharge current is 20kA.
- This device is must recommended to protect against indirect lightning strikes.
- It is the most using safety device in solar systems.
- It can be turned over to allow the phase/neutral cables to enter through either the top or the bottom.
- It’s Uc maximum continuous operating voltage is 1000VDC.
- The Up protection level is 4.0kV.
- The operating temperature is -25°C to 60°C and the storage temperature is -40°C to 85°C.
.
