CS6W-585TB-AG – 585W N-Type Bifacial TOPCon Solar Module ☀️
Overview
-
⚡ 585W High Power – Perfect balance of power & efficiency for large-scale use
-
🛡 Long Warranty – 12 years product + 30 years linear power guarantee
-
🧪 TOPCon Technology – Excellent reliability, low degradation
-
🏭 Commercial & Utility Ready – Rooftop, ground-mount, and tracker compatible
-
🌍 Certified Worldwide – IEC, UL, ISO, CE, MCS, UKCA approved
Description
CS6W-585TB-AG – 585W N-Type Bifacial TOPCon Solar Module datasheet
-
🔋 585W front-side output with 22.6% efficiency
-
🌞 Up to 80% power bifaciality for extra rear-side generation
-
📈 Bifacial gain potential: +5% → 614W, +10% → 644W, +20% → 702W
-
🧊 Low temperature coefficient (-0.29%/°C) ensures high yield in hot climates
-
📉 Low degradation rate – ≤1% first year, ≤0.4% annually after
-
🏗 Robust dual-glass (2.0 mm front & back) with anodized aluminum alloy frame
-
🌦 Withstands 5400 Pa snow & 2400 Pa wind loads
-
❄ Operates reliably from -40°C to +85°C
-
🪛 Factory-fitted 4 mm² cables with customizable length options
-
🏅 Certified for IEC 61215, IEC 61730, IEC 61701, IEC 62716, ISO9001, ISO14001, ISO45001
-
📏 Dimensions: 2278 × 1134 × 30 mm, weight 32.3 kg
